Janisol Arte 2.0 door

#JANSEN

Slim face widths and various design options, such as single-leaf, double-leaf, different threshold variants (including barrier-free), CE labeling, with or without sash bars, and multiple lock versions, are available. The doors can be crafted from a wide range of materials, including steel, stainless steel, and Corten steel. Janisol Arte 2.0 doors are an ideal choice for both renovations of existing buildings and new constructions where architectural flexibility is sought.

System description

Field of Application

Renovation and new construction
Non-load-bearing partitions or replacement wallsMaterials / Surface
Strip-galvanized steel, suitable for powder coating or enameling
Stainless steel 1.4401, bright or polished
Corten steel

Element Types

Single- and double-leaf doors, with or without fixed side sections or skylights, capable of opening inwards and outwards
Sheet metal-clad doors with or without glass cut-outs

performance characteristics

Equipment

3D screw-on hinges made of stainless steel
Integrated door closer
Designer glazing beads
Mortise lock and multipoint lockSpecial Technical Characteristics
Construction depth: 60 mm
All-glass look

Product details

Test Certificates

CE label in accordance with product standard EN 14351-1
– Tightness against heavy rain up to Class 8A (450 Pa)
– Air permeability up to Class 4 (600 Pa)
– Resistance to wind load up to Class C5/B5 (2000 Pa)
– Airborne sound insulation up to Rw 45 dB
– Heat transmission coefficient UD > 1.9 W/m²K
Shear coupling in accordance with EN 14024
Mechanical strength in accordance with EN 13115 up to Class 4
Impact resistance in accordance with EN 13049 up to Class 4
Durability in accordance with EN 12400 Class 7 (500,000 cycles)
Prefabricated barrier glazing in accordance with DIN 18008-4
