Janisol Arte 66

Slim Tilt and Turn Windows Made from Steel Profiles

The Janisol Arte 66 system offers a new variation with a basic depth of 66 mm, enabling the use of stronger glass and vent heights up to 2300 mm. This system is particularly suited for listed buildings that require narrow frames while allowing for modern turn/tilt openings. Concealed fittings ensure a seamless, uniform design with uninterrupted clear lines, meeting the aesthetic demands of architects and developers. The Euro grooves simplify the installation of fittings, and the new glazing bead system facilitates pane installation. Fabrication follows the reliable processes of Janisol and Janisol Arte 2.0 steel profiles, ensuring process consistency.

Benefits:

  • Modern turn/tilt opening
  • Compatible with Janisol Arte 2.0
  • Concealed fittings for a clean design
  • Free choice of handles for customization

System description

Field of Application

  • Suitable for renovation and new construction projects
  • Ideal for non-load-bearing partitions or as a replacement wallMaterials / Surface Finish
  • Strip-galvanised steel
  • Corten steelWindow Types / Opening Options
  • Side-hung and turn/tilt windows
  • Windows with meeting stile, single and double-vent, inward-opening
  • Inward-opening bottom-hung window
    – Spring catch mechanism
    – Toplight opener
    – Motorised window operation
    – Windows with integrated fittings
  • Fixed glazing options

performance characteristics

Special Technical Features

  • Basic depth of 66 mm
  • Vent depth of 70 mm
  • Extremely narrow face widths: Fixed glazing: 30 mm
  • Window vent: 28 mm
  • Window meeting stile design: 76 mm
  • Easy fabrication process
  • Supports window sizes up to 1400 x 2300 mm
  • Accommodates glass thicknesses ranging from 15 to 53 mm
  • Maximum sash weight of 180 kg
  • New glazing beads equipped with innovative fixing studs for enhanced installation

Product details

Test Certificates
CE marking in accordance               with product standard EN 14351-1

  • Resistance to wind load: C5 (2000 Pa)
  • Watertightness: up to class 9A (600 Pa)
  • Sound reduction: up to 47 dB
  • Thermal transmittance: Uf from 1.9 W/m²K
  • Air permeability: class 4 (600 Pa)
  • Load-bearing capacity of safety devices: met
  • Mechanical strength: class 4
    Impact resistance: class 4
  • Prefabricated glazing suitable for safety barrier loading: DIN 18008-4 met

TECHNICAL DATA & DOWNLOADS

Download supporting documents & brochures here
Janisol Arte 66 Thermally insulated slim turn/tilt windows and fixed lights
