Janisol folding partition

The Janisol folding partition, built on the thermally insulated Janisol system, offers versatile functionality. It can serve as a room divider or be applied for exterior use. This trusted system, newly designed for flexible openings, allows for inward or outward folding. Its slender steel profiles and narrow face widths deliver robust, durable, and long-lasting folding partitions.

System description

Materials/Surface Finishes:

  • Strip-galvanised steel, suitable for powder coating or stove-enamellingElement Types:
  • Manual folding-sliding glass doors
  • 2 to 6 leaves
  • Inward- and outward-opening options
  • Flexible leaf arrangement



performance characteristics

Equipment:

  • Fittings support up to 200 kg
  • Leaf weight up to 100 kg
  • Leaf widths up to 1,000 mm
  • Leaf heights up to 2,900 mmSpecial Technical Features:
  • Leaf installation depth: 60 mm
  • Frame installation depth: 60 mm
  • Infill elements: 13 – 37 mm
  • Face width from window overlap area: 105 mm
  • Face width (leaf with frame): 82.5 mm

Product details

Test Certificates:

  • CE marking in accordance with product standard EN 14351-1
  • Tightness against heavy rain: up to class 8A (450 Pa)
  • Air permeability: up to class 4
  • Wind load resistance: up to class C3/B3
  • Operating forces: class 1
  • Airborne sound insulation: up to Rw 45 dB
